| Separation Type | CMS and OWS Filtration |
|---|---|
| Types of Separation | Suspended solids reduction down to 20-microns |
| SIOSTM Dimensions | 1.47m Long x 1.02m Wide x 1.69m High |
| Model | Length | Width | Height |
|---|---|---|---|
| SIOSTM-30 | 1188mm | 367mm | 1246mm |
| SIOSTM-100 | 1186mm | 674mm | 1246mm |
| MAIN COMPONENTS |
|---|
| 1 GUTTER PUMP |
| 2 CMS-OWS SOLIDS FILTRATION and OIL-WATER SEPARATION |
| 3 TRANSFER PIT WITH PUMP |
| 4 RAIN DIVERSION VALVE |
| P SINGLE PHASE POWER |
| S SEWER DISCHARGE |
| R RAIN WATER DIVERSION |
| D SLUDGE DRAIN |
| W WASH WATER TO BE PLUMBED THROUGH THE FLOW DETECTION CIRCUIT |
| Pad Qty: | 0.5 Pad |
| Wash Bay Size: | 2.4m Long x 3.5m Wide |
| Walls: | 1.2m | 1.8m | 2.4m High |
| Ramps: | 0.6 Wide x 1.5m Long each |
| Gutter: | Galvanised with float switch |
| Weight Capacity: | 2 Tonne per axle rating |
| Warranty: | 10 Years structural warranty |
| Pad Qty: | 1 Pad with 1.1m wide walkways |
| Wash Bay Size: | 6.0m Long x 4.7m Wide |
| Walls: | 2.0m High |
| Ramps: | 0.9 Wide x 1.5m Long each |
| Gutter: | Galvanised with float switch |
| Weight Capacity: | 2T and 12T (Tonne per axle rating) |
| Warranty: | 10 Years structural warranty |
| Pad Qty: | 6 Pads |
| Wash Bay Size: | 14.4m Long x 6.5m Wide |
| Walls: | 1.2m | 1.8m | 2.4m High |
| Ramps: | 2T – 1.5m Long & 12T 2m Long |
| Gutter: | Galvanised with float switch |
| Weight Capacity: | 2T and 12T (Tonne per axle rating) |
| Warranty: | 10 Years structural warranty |
